Springs / Wave Springs / Nested Wave Spring

WN-387 B

Print this page

Images

Product Image

CAD

Part Data

  • Operates In Housing Diameter • Dh 3.875 inches
  • Shaft Diameter Clearance • Ds 3.255 inches
  • Section • S 0.233 inches
  • Thickness • T 0.030 inches
  • Wave Spring Design Nested
  • Free Height • Fh 0.169 inches
  • Number Of Waves 4
  • Number Of Turns 3
  • Work Height • WH 0.169 inches
  • Spring Rate (Ref) 881 lbs./in.

Performance Data

  • Load @ Work Height • Wh 192 lbs.
  • Load @ Free Length 1 lbs.

Documentation

Description

Nested, Inch Wave Springs. Two to three turn wave springs are coiled in parrellel to allow for higher loads. The spring rates increase proportionally to the number of turns, providing for a high, accurate load in a very small axial space.

Request QuoteRequest Samples

Custom solutions

Can’t find what you’re looking for in an existing product, need a modified version of one of our standard parts, or simply aren’t sure what part you need?

Submit your custom specifications

Need help? Contact our Engineering team

Notes

CAD Models are provided for informational purposes only and may not represent the final part you receive.  Manufacturer assumes no responsibility for any such inconsistencies , and disclaims any liability to any party for any loss, damage, or disruption which may arise therefrom. Always contact Manufacturer for final measurements when specified in your design.
